The Subzero Engineering Velocity Adjustor is the most efficient way to balance subfloor air pressure in data centers.
On this page:
The Subzero Engineering Velocity Adjustor is the most efficient way to balance subfloor air pressure in data centers. Alpine Power Systems is a value-added reseller of Subzero Engineering products.
The Velocity Adjustor is designed to lower velocity at the AC discharge to eliminate sub floor vortices that are formed when two high velocity currents of air converge. Slowing the air increases pressure, and this in turn creates a consistent supply of air to any part of the data center. The supply airflow through the sub floor plenum is the foundation of any cooling program. Inconsistent supply, due to high velocity airflow from CRAC, units prevents cooling air from getting to the computer intake, especially at the top of the rack. A balanced supply volume is essential in order to match the kW load in each cabinet.
Velocity Adjustor Key Features:
Easy to Install
Custom Sizes Available
Made of Non-flammable Material
Provides Consisten Air Supply
Velocity Adjustor Technical Specifications:
Outside Cover:
Physical Properties
Property:Units:Result:Â Thread Count#/in.Warp: 54Fill: 48Tensile StrengthLbs./in.Warp: 180Fill: 175ThicknessMils5-6Â Afterglow TimeSecondsWarp: 1.5Fill: 1.5Char LengthInchesWarp: .70Fill: 1.5AfterflameSecondsWarp: 1.0Fill: 1.0Tearing StrengthLbs.Warp: 8.0Fill: 7.5
Standard Sizes
6" x 24"24" x 24"12" x 24"24" x 32"18" x 24"
Features
Will not igniteWill not meltWill not dripFlexibleWill not shrink or stretchWill not rotMinimal smoke emission
Flammability
Designed to meet:NFPA 258NFPA 701 (UL-214) Small Scale
Shipping:
Physical Properties
Property:Result:Weight4-5 oz./y2
Alpine Power Systems is a value-added reseller of Subzero Engineering products. Alpine can provide thermal management services on all Subzero products including engineering, installation, preventative maintenance, monitoring and recycling. Alpine has 25 locations and 200 technicians that are available to provide service nationwide. Call our inside sales group at 877-993-8855 for assistance.
